Techcon TS50BP Basic Benchtop Meter Mix Dispensing System

SKU: TECHCON TSM50BP-3LITER-1


We're local! Get onsite help with planning, installation or training for your new dispensing system. Learn more

Used to Dispense

  • 1:1 and 2:1 Adhesives
  • 4:1 and 10:1 Adhesives
  • Epoxies
  • MMA

When to Use the Techcon TS50BP Benchtop Meter Mix Dispensing System

The Techcon TS50BP is a simple to use and configure system for low to medium viscosity two part adhesive resins. It provides a low cost way to dispense two part materials for bonding, potting, encapsulating, sealing and more. Use this system for manual or semi-automated applications like product assembly, electronic potting and more.

Details

The Techcon TS50BP is a complete benchtop meter mix system for mixing and dispensing two part adhesives. It provides a low cost, simple way to dispense common adhesives like epoxies, MMA's and more.

The Techcon TS50BP can dispensed a wide range of fixed ratios including 1:1, 2:1, 4:1 and 10:1. This benchtop meter mix system is pneumatically powered using positive displacement pump technology to ensure accurate, repeatable mixing and dispensing of two part adhesive resins.

The TS50BP is activated using a foot switch and can dispense in shot sizes from 1 to 50cc with +/- 1% accuracy.

Common Applications

  • Bonding
  • Potting & Encapsulating
  • Sealing
  • Insulating

Specifications

TS50BP

MIX RATIO OPTIONS

1:1, 2:1, 4:1

SHOT SIZE RANGE

1 - 50 CC

MAXIMUM VISCOSITY

500,000 cps.

ACTIVATION

FOOT SWITCH

METERING REPEATABILITY

+/- 1%

OPERATING PRESSURE

100 psi

MIXING

DISPOSABLE STATIC MIXERS

TANK CAPACITY OPTIONS

3, 5, 7, 10 Liter

MECHANISM

PARALLEL DRIVE, POSITIVE DISPLACEMENT

CONTROLL PANEL

ANALOG

POWER (DIGITAL)

SINGLE PHASE 110V & 220V

DIMENSION

23.23" X 14.96" X 21.26"           (590 X 380 X 540 mm)

WEIGHT

88 lbs (40 kg)

Authorized Distributor

Dispensing.com is an authorized distributor of Techcon dispensing equipment.
